Raising pH with Air

Spas, Splash pads, and Waterpark rides…

Ever wonder why the pH tends to run high in certain bodies of water no matter what you do? Always adding acid? Spas, Splash pads, swimming pools with water features, and literally everything at a waterpark. They all have one thing in common.

AERATION!

When water is aerated, it creates turbulence. The turbulence then causes the aqueous CO2 (carbon dioxide) to outgas. Outgassing of COfrom water results in an increase in pH. Aeration is the only means of increasing pH that will not increase the Total Alkalinity. This is both beneficial and problematic.

At Aquatic Facility Training & Consultants, we think it’s important to know the “why” behind things. To understand the reason for the increased consumption of acid at these facilities. If you can embrace the science in what we do, swimming pools become increasingly easy to care for.

My pool, at my house; the pH always runs on the low side. My yard has long leaf pine. Pine needles, when green, are acidic. Even if they do not fall directly into the pool, when the needles get wet, they drip. This drives the pH down. My pH, left to its own, would be a consistant 7.0

Four years ago, with the knowledge of aeration, I decided I would run an experiment. I took a single return jet (where the water comes back into the pool through the wall) and loosened the collar. I aimed the jet toward the surface so that it would cause that ripple in the water. Within three days, the pH in my 15′ x 30′ rose to 7.6. Between the turbulence caused by the jet and the acidity from the pine needles above, my pH has remained between 7.5 and 7.6 for the past four years without the need to add a chemical for adustment; up or down. Wouldn’t it be great if you could harness this power and not have to worry about a pH too low?

What about that pool you have on your service route where the pH always runs high (saltwater pools excluded)? Maybe it doesn’t have a water feature. Next time you are there, take a look at where the return jets are aimed. A lot of times home owners will aim their jets upward, because “they like to see the water move… Your real problem is not the pool. You have been fighting science and losing the battle against aeration.  Loosen the collars and aim those jets back downward – pH problem solved.

Many times, during the summer months, competition pools utilize water cannons to cool the water temps. These cannons shoot water through the air in an effort to keep the water within the USA Swimming guidelines for competition (between 25 to 28 degrees Celsius (77 to 82.4 degrees Fahrenheit)). This can be a double edged sword. The cannons are very effective at reducing water temperature. However, they do create a ?-ton of turbulence. This drives the pH upward, but remember earlier I had mentioned that aeration would not raise the Total Alkalinity? This is a problem.

So if the aeration created by the water cannons causes the pH to rise, we will need to add acid to lower it. Makes perfect sense, right? Here’s the thing: it is impossible to add acid to lower the pH without it also lowering the Total Alkalinity. But, again, the turbulence did not raise the Total Alkalinity; just the pH. That means that our continuous feed of muriatic acid necessary to counter balance the aeration of the cannons and keep the pH in check has driven our Total Alkalinity to a level too low. It is not uncommon to see that some type of sodium bicarb feed system has been added to these pools to counter the dose of acid.

An alternative at competition pools to muriatic acid is the injection of carbon dioxide (CO2). When COis added to water if forms carbonic acid (H2CO3) Carbonic acid is very effective at lowering pH. Unfortunately, injecting COto form carbonic acid (H2CO3) is the only method of lowering pH that will also increase the Total Alkalinity. Ultimately, the pool would then require the addition of muriatic acid.

I don’t want to delve deeply into the MYTH at this point in time because more information is coming in the near future. Still, we need to understand that it is impossible to add acid to lower the Total Alkalinity without lowering the pH, and vice versa. Many have said in the past, and many still believe, that the method of introduction of acid to water will enable a person to lower one without affecting the other. This is simply untrue.

pH stands for potenz Hydrogen, which translates from German to “the power of Hydrogen” Anytime acid is added to water it increases the Hydrogen ion level. If you add acid to water in order to lower the Total Alkalinity (as our CO2 method above would eventually require), the Hydrogen Ion level will increase. As pH is the measurement of the water’s demand for acid (more specifically, hydrogen activity measured in the converse), the pH would lessen; a low pH indicating a low demand. In short, if you increase the amount of Hydrogen Ions while lowering the TA, does it not make sense that you will affect a reading that measures Hydrogen ion concentration in that soultion (the power of Hydrogen (pH)) ??? The same holds true when the levels are increased (Yet another entirely different conversation), with exception to aeration. This leaves aeration the only method of altering pH with an effect something else, or does it? What would be the impact of aeration on water temperature as noted with the water cannons above?
